| SPECIFICATIONS |
| Power range |
0.37kW – 5.5 kW (0.5HP – 7.5HP) |
| Speed |
2880 rpm |
| Version |
Single Phase, 200 – 240V, Three Phase, 380 – 415V, 50 Hz, A.C. Supply |
| Maximum total head |
395 metre (39.5 bar) |
| Maximum flow rate |
18000 LPH (18 M3 / Hr) |
| Maximum outer diameter in mm |
97 & 98. |
| Nominal outlet size in inches |
1 ¼, 1 ½, 2 & 2 ½ |
| Degree of Protection |
IP 58. |
| Direction of Rotation |
Clockwise from driving end. |
| Thrust Load |
1500 lbs. |
| Minimum cooling flow along the motor |
0.15 m/sec |
| Type of duty |
S1 (Continuous) |
| Method of starting |
Direct on Line, Capacitor Start Capacitor Run (CSCR) / Permanent split Capacitor (CSR) |
| Maximum starts per hour |
12 times. |
| Mounting Standard |
As per NEMA |
